Vacuum Spray Cooling
Tank For Pipe















































































































Features
  Utilizes vacuum pumps with ratings of 3 HP to 100 HP.
  Cooling capacity of 30 KGS/hr to 500 KGS/hr.
  Positions can be adjusted front and back or left and right. Front-back movements is done by a stepless inverter motor which can make either high-speed or incremental adjustments.
  Water flowmeter cooling device is displayed to allow control of die temperatures and monitor temperature records.
  A specially designed die clamp frame allows vertical and horizontal adjustment to accept molds of all sizes.
  A phase control electrical protector guards against errors in vacuum pump rotation.




ERT Series


ERT-4500L Series
ERT-6000XL Series
ERXT-Series






Specifications
ERT3000
ERT3000X
ERT3000L
ERT4500L
ERT6000L
Adjustable Length For Back And Forwards
750
750
750
750
750
Adjustable Length For Right And Left (MM)
50
50
50
50
50
Adjustable Length For Up And Down (MM)
100
100
100
100
100
Length Of Calibration Table (MM)
3000
3000
3000
4500
6000
MAX. Products Width (MM)
300
300
300
300
300
Number Of Vacuum Pump
1
2
3
3
2
1
Vacuum Pump Power (HP)
5
5
5
5
5
7.5
Drainage Pump (HP)
1/2
1/2
1/2
1/2
1/2
Number Of Water Flow Valve
8
16
24
32
32
MAX. Exhaust Volume (M3/MIN)
1.9
3.8
5.7
7.6
7.6
Installed Electric Power (KW)
5.5
9.5
13.5
17.5
17.5
Inflow Pipe Diameter (INCH)
1.5
2
2
2
2
Exhaust Outlet Pipe Diameter (INCH)
1.5
2
2
2
2
Overall Sizes(MM)
Length (A)
3290
3290
3290
3500
6500
Width (B)
800
800
800
1000
1000
Height (C)
1850
1850
1850
2000
2000
Weight (KG)
500
600
700
1200
1800

ERXT600
ERXT800
ERXT1000
ERXT1200
Adjustable Length For Back And Forwards
1000
1000
1000
1000
Adjustable Length For Right And Left (MM)
50
50
50
50
Adjustable Length For Up And Down (MM)
100
100
100
100
Length of Calibration Tablet (MM)
4000
4000
4000
6000
MAX. Products Width (MM)
600
800
1000
1200
Number Of Vacuum Pump
4
1
3
1
3
2
2
Vacuum Pump Power (HP)
10
20
10
20
10
20
10
Drainage Pump (HP)
1
1
1
1
Number Of Water Flow Valve
32
32
32
32
MAX. Exhaust Volume (M3/MIN)
14
20
32
40
Installed Electric Power (KW)
35
50
70
85
Inflow Pipe Diameter (INCH)
2
2
2
2
Exhaust Outlet Pipe Diameter (INCH)
2
2
2
2
Overall Sizes(MM)
Length (A)
5000
5000
5000
5000
Width (B)
1200
1400
1600
1800
Height (C)
2000
2000
2000
2000
Weight (KG)
2000
2400
2800
3500


Specifications are subject to change without notice.


..........................................................................................................................................................................................................................................................
