Features
  Our company has designed & produced three model mixers which against various material mixing:
  CL-FA: Adopts fixed rev. speed motor drove which suitable for general material mixing.
  CL-FB: Adopts pole change 2 steps speed motor drove which suitable for large volume material mixing.
  CL-FC: Adopts stepless variable speed inverter motor drove which can be against different material to change the mixing speed.

  COOLING AND BLENDER SYSTEM FEATURES
  This kind of machine is suitable to be used for the purpose of cooling more output. Baffle plate(s) (part A) can enlarge cooling area and advance the speed of cooling.




Mixer







Specifications
1.MIXER
Model
FB200
FB300
FB400
FB500
FB750
Tank capacity
250L
350L
420L
550L
800L
Feeding capacity
120-150L
180-230L
230-300L
300-360L
450-540L
Mixing weight
75kg
120kg
150kg
180kg
270kg
Power
30/60HP 4/8P
50/100HP 4/8P
62.5/125HP 4/8P
62.5/125HP 4/8P
100/200HP 4/8P
Machine size
2,300 x 900 x 900mm
2,700 x 1,100 x 2,200mm
2,800 x 1,200 x 2,300mm
2,800 x 1,200 x 2,300mm
3,300 x 1,350 x 2,450mm
Machine weight
1,800kg
2,500kg
3,400kg
3,600kg
4,300kg

2.COOLING AND BLENDING SYSTEM
Model
MB400
MB600
MB800
MB1000
MB1500
Tank capacity
400L
600L
800L
1000L
1500L
Feeding capacity
150-300L
200-400L
350-650L
350-700L
600-1,000L
Mixing weight
150kg
240kg
350kg
360kg
540kg
Power
15HP 4P
20HP 4P
20HP 4P
25HP 4P
35HP 4P
Machine size
1,850 x 1,050 x 1,600mm
2,050 x 1,300 x 1,750mm
2,300 x 1,500 x 1,800mm
2,450 x 1,600 x 1,900mm
2,600 x 1,800 x 2,000mm
Machine weight
1,200kg
1,500kg
2,300kg
2,500kg
3,000kg
Specifications are subject to change without notice.

..........................................................................................................................................................................................................................................................
